Steel Core And Hemp Core Rope

Here are two types of wire ropes, steel core wire rope and hemp core wire rope specifications:

Steel core wire rope specifications:

• DIA= 22.0MM.
• Strand= 6×19, CONST. 6 (12+6F+6+1)WR.
• Breaking Load= 31.83MTN (312 KN).
• UTS= 180 KGF/mm² (1770 N/mm²), Un-Galvanized.
• Right Hand Regular Lay, As PER ISO-2408-73.

Type 2

• DIA= 32.0MM.
• STRAND= 6×26, CONST. 6 (10+5/5+5+1)WR.
• Breaking Load= 65.91 MTN (646 KN).
• UTS= 180 KGF/mm² (1770 N/mm²), Un-Galvanized.
• Right Hand Regular Lay, As PER ISO-2408-73.

Type 3

• DIA= 18.0MM.
• STRAND= 6×36, CONST. 6 (14+7/7+7+1).
• BREAKING LOAD= 20.80 MTN (204 KN).
• UTS= 180 KGF/mm² (1770 N/mm²), Un-Galvanized.
• Right Hand Regular Lay, As PER ISO-2408-73.

Hemp Core Wire Rope Specifications:

• DIA= 8.0MM.
• STRAND= 6×19, CONST. 6 (9+9+1) FC.
• Breaking Load= 3.82 MTN (37.5 KN).
• UTS= 180 KGF/mm² (1770 N/mm²), Un- Galvanized.
• Right Hand Regular Lay, As PER ISO-2408-73.

Type 2

• DIA= 24.0MM
• STRAND= 6×19, CONST. 6 (9+9+1) FC.
• Breaking Load= 34.36 MTN, (337KN).
• UTS= 180KGF/mm² (1770N/mm²), UN GALVANIZED.
• Right Hand Regular Lay, As PER ISO-2403-73.

Type 3

• DIA= 36.0MM.
• STRAND= 6×37, CONST. 6 (18+12+6+1) FC.
• BREAKING LOAD= 68.97MTN (676KN)
• UTS= 180KGF/mm² (1770N/mm²), Un-Galvanized.
• Right Hand Regular Lay, As Per ISO-2408-73.
