Rotation-resistant wire ropes are different from standard wire ropes because they're designed to reduce rope torque. Modes of failure and wear for rotation-resistant wire ropes can differ from those for standard wire rope constructions. The very nature of these wire ropes requires special handling, selection and usage not encountered with standard constructions.
Rotation-resistant wire ropes should not be used with swivels that allow rope rotation - or in single part lifts where the load can rotate. Rotation will cause a reduction in strength, unequal loading in the wire rope and possible rope unbalance.
Because rotation-resistant wire ropes are special, there are separate design, maintenance, inspection and removal criteria established for them by applicable industry regulations and standards.
wire rope follows a rigorous program of testing through the production process and the products with slightest of defect are eliminated. We have devises of superior quality practices in our company too and make sure that each and every product we manufacture bears the stamp of excellence.
Federal Specification RR-W-410C/ A.P .I | ISO 2408/British Standards | |||||
---|---|---|---|---|---|---|
Num. Breaking Load | Min. Break Load | |||||
Nominal Diameter | Approx. Weight | IPS | Nominal Diameter | Approx. Weight | 180 Grade | |
in | lb/ft | lb | mm | kg/l00m | tonne f | |
3/8 | 0.236 | 12200 | 9 | 29.9 | 4.92 | |
7/16 | 0.32 | 16540 | 11 | 44.7 | 7.36 | |
½ | 0.42 | 21400 | 13 | 62.4 | 10.30 | |
9/16 | 0.53 | 27000 | 14 | 72.3 | 11.90 | |
5/8 | 0.66 | 33400 | 16 | 94.5 | 15.60 | |
3/4 | 0.95 | 47600 | 19 | 133 | 21.90 | |
7/8 | 1.29 | 64400 | 22 | 179 | 29.4 | |
1 | 1.68 | 83600 | 26 | 250 | 41.1 | |
1 1/8 | 2.13 | 105200 | 28 | 289 | 47.7 | |
1 ¼ | 2.63 | 129200 | 32 | 378 | 62.2 | |
1 3/8 | 3.18 | 155400 | 35 | 452 | 74.5 | |
1 ½ | 3.78 | 184000 | 38 | 533 | 87.8 | |
1 5/8 | 4.44 | 214000 | 40 | 591 | 97.3 | |
1 ¾ | 5.15 | 248000 | 44 | 715 | 118.0 | |
1 7/8 | 5.91 | 282000 | 48 | 850 | 140.0 | |
2 | 6.72 | 320000 | 52 | 998 | 164.0 |
